24V 800W Electric shaft for scooter
Product Name : 24V 800W Electric shaft for scooter
Product Intro : 1.Widely use. 2.With 24v 800w. 3.We are manufacturer. 4.No=load current:9A.
Product Intro : 1.Widely use. 2.With 24v 800w. 3.We are manufacturer. 4.No=load current:9A.
Specifications :
Description : Transaxle
Part Number : HQ-005E
Operating Voltage : 24VDC
Output Power : 800W
No-load Current : 9A
Motor Speed ±5% : 3000RPM
No-load Output Speed : 240RPM
Gear Ratio : 12.2:1
Sound Level : 68
Brake Torque : 3Nm
Gearmotor Rated Torque : 12Nm
Motor OD : Φ 68mm
Output Shaft OD : Φ 19mm
Weight : 7Kg
Size : 580*270*220mm
